| L=74.2[μH] | Ls=80[μH] | Cout=333.33[μF] | Ton=0.75[μs] |
| Toff=6.67[μs] | d=0.112[.] | Iin_avg=2.24[A] | Imax=1[A] |
| iripple=4[A] | Iprim=37.45[A] | Isec=12[A] | Iin=0.56[A] |
| Imag=13.45[A] |
Gate signal for the Mosfet:
Primary winding voltage:
Current through the primary inductor:
ipmin=16; ipmax=37.45
Secondary winding voltage:
Current through the secondary inductor:
ismin=8; ismax=12
Voltage across the Inductor
Current through the inductor:
Voltage across the Mosfet
Current through the Mosfet:
Voltage across the Diode VD1A /D1B
Current through the Diode D1A /D1B:
Current through the Diode D2 :
Current through the Diode D3:
